A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 321
e formulas is appended, which gives the lap and travel whenthe required angles are known; but as the calculation of these angles fromgiven piston positions is somewhat tedious, a second table is added, show-ing the crank angles for various piston positions, and for connecting-rods ofsuch lengths as… … ce/t//v\-^ ^ {centre Let c = length of connecting-rodlength of stroke distance from end of stroke to given position of piston ~ length of stroke c = distance from centre of cross-head to centre of shaft.C - angle of crank. (Note.—The forward stroke in direct-acting engines is that in which…
