shown in Fig. 754, and the travel j-, = 2(9+ O2 is greater thanin the first position. If the expansion slide AB, Fig. 755,cuts off at each end A and B, the expansion can only be Fig. 755. D-i … altered by changmg the travel of the slide. Here expan-sion occurs while the slide moves the distance s ^= A i a- 2 B= 2 A I, and the eccentric through the angle p = 2 <C O C i.But, for the eccentricity CE = r, we have sin. O C I — sin. ^ (3 = 2 r 3.36 HEAT, STEAM, AND STEAM ENGINES. L§ 468.…
