than F, assists some-what the motion in the direction F D, and hinders that inthe opposite direction. The exhaust steam flows, afterhaving performed its work in the large cylinder, throughZ to a pipe Jll, and then by another pipe N to the con-denser K. The admission and release of the steam… … 358 HEA T, STEAM, AND STEAM ENGINES. L§ 477. (9, P, and Q, and the levers R and T. We also see in thefigure the crank [Fand connecting- rod X, as also the fly-wheel Y F, by means of which the reciprocating motion ofthe piston rod is converted into a nearly uniform motion ofrotation. (See Practical…
