n rod, andcarrying the counter-weight G at itsother end. The pencil during thestroke thus describes a cvirve D D, thearea of which measures the work per-formed by the piston. If, therefore,we divide the work thus determinedby the length of stroke, we obtain the mean pressure of thesteam upon the… … § 492.] THE STEAM ENGINE. 401 If, however, q is the tension during descent of K, and y,the force necessary to extend the spring, <! + J,. Uniting these equations, we have forthe moving force of K per square inch, g Fig. 788. P j\ + a- {a - J,) J\ + J\ If the forces of compression andextension of…
