V V and L are closed, and the ringvalve W W is opened, and in both spaces B B V andW W K WQ have heated air. The piston A A is, therefore, 5i6 HEAT, STEAM, AND STEAM ENGINES. [§515. forced forwards by the difference of pressure between theheated air and the outer air, while the pressure of… … N,Ui The diagram II. in Fig. 811 gives a graphical repre-sentation of the relation between the motions of both pis-tons and the space between them. The horizontal linesgive the travel of the pistons, and the verticals give thetravel of the crank on the fly-wheel D. While the crankmakes a complete…
