A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 559
rod, eccentric, ratchet wheel, etc., is con-nected with a shaft W,, made to revolve by gear wheelsz, 2,. The vertical sections I, II, III, in Fig. 817, show theslide valve in three different positions. In the centralposition I, while the piston reaches the end of its stroke,the used gas escapes… … § 5I9-] THE STEAM ENGIiVE. 545 thi-ough ;;/ and ;/, while a portion passes through ;/, to thechamber a^, and is ignited by the gas jet /. Finally, in III,
Mechanics, Applied · Mechanical engineering
