Manual of ecclesiastical architecture. Comprising a study of its various styles, the chronological arrangements of its elements, and its relation to Christian worship (1897)

Martin, William Wallace, 1851- · Cincinnati, Curts & Jennings; New York, Eaton & Mains · leaf 312

An illustration from Manual of ecclesiastical architecture. Comprising a study of its various styles, the chronological arrangements of its elements, and its relation to Christian worship, 1897, leaf 312
»% I —T r n 1 … PIER VARIATIONS. thirteenth and fourteenth centuries, in which appearedthe pointed groined vaults, there are two forms of theclustered pier: one (7) has four principal mouldings,with intermediate ones, corresponding to the arches andribs of the vaulting; the other form {8) has a round,central mass,…

Church architecture
