Fig. 5. … Fig. 6. pierces the vertical plane ; b being the intersection of bb\ a per-pendicular to the ground line from b, where the horizontal projec-tion ab intersects it; and ab, the vertical projection of the givenline. And the point b, Fig. 81 ; the points b and d, Fig. 82 ; thepoint O, Fig. 86; the…
