f, K, and flange W, the intersection of thecentre lines BK and mm, is the centre for the curves which inter-sect the centre line AK; the-corners, 1 1, of the nuts, v,v\ are thecentres for the curves that cross the centre line, vv; and theremaining outlines of the shelf are tangents to the arcs thus… … ^7 -,1 V ! R 1 1 IKON CONSTRUCTIONS. 121 I. The remaining circles and larger hexagon, u\ of this portionof the plan, have the intersection of the centre lines for a centre; andmay be drawn by measurements independently of the elevation, orby projection from the elevation, after that shall have…
