Kilbon, George B. (George Baldwin) · Boston, Lee and Shepard · leaf 84
Fig. 151. USE OF CHISEL AND GOUGE. 73 With rule and pencil restore the points that are to be apicesof pyramids. Make a cardboard templet to the angle whichthe base of a pyramid is to make with an edge; use it to drawnecessary pencil lines, and chisel V grooves crosswise of theboard, leaving rows of… … Problem III. Chamfered Corners. — Make a square prism8 in. X If i^i- X If in. Kapid workmen may plane the ends.Square around fine pencil lines 1 in, and 1| in. from each end.Set the gauge | in., and gauge two lines on every side betweenthe two If in. squared lines, as in Fig. 153. Join the pointsa…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
