angleby making A E = 1 in. and A F = SjV in., and drawing E F.Set the bevel to this second standard angle, use it to draw thetwo bevelled lines shown in Fig. 183, continue these lines TO MAKE A BEVELLED BOX OB CABD-BECEIVEB. 87 square across the bevelled edge of the work, use the bevel onthe back… … Fig. 184. Brad-awl three holes in the longer piece L, giving them adirection parallel to the bevelled end and edge, and, using2 in. No. 13 steel-wire finish nails, nail it to the shorter pieceS. Cut away the small portion of L that now stands abovethe plane of the upper edge of S, and the work will…
