Kilbon, George B. (George Baldwin) · Boston, Lee and Shepard · leaf 98
d edge, and, using2 in. No. 13 steel-wire finish nails, nail it to the shorter pieceS. Cut away the small portion of L that now stands abovethe plane of the upper edge of S, and the work will appear asin Fig. 180. Fold a small piece of No. ^ sand-paper over a small block,and sand the work, being… … Problem II. The Bevelled Box. — Fig. 185 is a perspectiveview of the bevelled box which is made from f in. white wood.Fig. 186 is three orthographic views. 88 ELEMENTARY WOOBWORE. Draw an elevation of the angle full size, as in Fig. 187, andthe slant height will be found to be 2| in. tfr - 12Tn. n…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
