Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 195

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 195
rom an actuat-ing means disposed at one side of the loom, thusreadily accessible for the fixer. 186 Manufacture of Narrow Woven Fabrics. The guide roll 12 is secured to the batten by screws %13, so that the device can be used on either a rightor left hand batten, by simply changing the guidepulley… … side projections 16 to which the flexible connections11 are secured. Said projections 16, and consequentlythe rack bar 3 are thus limited in their reciprocatingmovements lengthwise of the batten, the said projec-tions riding on the ledge 17 (Fig. 238) thus effectivelypreventing any tipping movement…

Weaving · Textile fabrics

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
