point of attachment on the reducing motion.A strong inelastic cord, with an attached hook, is woundaround the bottom of the paper drum, and as the drum is re-volved, by this cord, it should not come up against its stops.When certain that this is the case and that everything is work-ing smoothly,… … Fig. 37.—Section ofIndicator. Fiiir. 36.—Indicator. Turn steam on slowly, to warm up the indicator and blow itfree of water, and when this is done shut off the steam and letthe pencil trace the atmospheric line on the card. Turn thesteam on full and bring the pencil point lightly against the…
