An illustration from The mariners' handbook; a convenient reference book for navigators, yachtsmen, and seamen of all classes, 1906, leaf 216
edo boat. Theseveral compartments designated by numbers are as follows.1, chain locker; 2, tank; S, torpedo hoist; 4. spare torpedoes;5, shaft for war heads; 6, crews quarters; 7, magazine; 8, store-room; 9, coal bunker; 10, boilers; 11, stoke hold; 12, mainengine;75, auxiliary engine; 14,… … 184 THE CLASSIFICATION OF WAR SHIPS
