d is the pitch. Therefore with a single thread worm (Fig. 21c) thepitch equals the lead and one revolution of the wormadvances the worm wheelone tooth. With a doublethread worm (Fig. 21b) thepitch equals one-half thelead and for each revolution the worm wheel is advancedtwo teeth. With a treble… … FIG.2IA
