ividual plates andto shear or cutting across at the point where they passfrom the one plate into the other. Bearing Value of Rivets.—The bearing value is usu-ally taken as equal to the rivet diameter multiplied bythe thickness of the plate multiplied by the safe bearingstrength of the material of… … F/6. 3. multiplied by the safe shearing strength of the rivetmaterial. One of three types of riveted joints is generally usedin practice, namely: 1st—Single riveted lap joint (seeFig. 3) in which the edge of oneplate laps the edge of the otherplate, with a single row of rivetsfastening the two…
