Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 111

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 111
the float R,which moves freely on the valve rod O, and refills the cylinder. The water under atmospheric pressure having then lost in momen-tum, the steam acting downward on the valve rod closes the main checkvalve, and through pressure exerted on the float, again forces water outof the cylinder… … WATER INLET SECTION VI. EXPLOSIVE MOTOR POWERAND APPLIANCES. Ill Section VI. EXPLOSIVE MOTOR POWER ANDAPPLIANCES. 265. THE LIGHTEST GASOLINE MOTOR. Duryea Power Co. type, Reading, Pa. The motor is a 6-cylinder, using gasoline as fuel, being of the opposedcylinder type, and workingon a 3-throw crank…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
