308. BASKET STRAINER.A perforated plate slid into a cylin-drical chamber with cover and yokein a line of suction pipe. Easilyremoved for cleaning. 309. Section showing perfora-tions in the strainer plate. 310. DOUBLE-BEAT FLAP VALVE. The reversed flap on the back of the main flapis a great relief… … £<=:=--:!== STILL. A tin-lined copper still and worm of twogallons capacity will yield about six gallonsof distilled water per day. Water is fed tothe inverted siphon at D, and is sealedagainst the low steam pressure by the dropof the bend at B. Still should not be overhalf full for best effect.…
