Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 145

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 145
_Li***^ -j^^jjat* 144 AIR-POWER MOTORS AND APPLIANCES. 354. PNEUMATIC MOISTENING APPARATUS. Com-pressed air is supplied to the atomizing nozzles at various points in a … factory by the main pipe A. The water is supplied by the smallerpipe below to the water nozzles, and is atomized and vaporized incontact with the air from the nozzles together with the induced airdrawn in by the jets. The wings guide the vapor toward the ceiling,and also collect the excess of water…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
