Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 146

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 146
aft is a handwheel or tiller, by-means of which the wagon may beguided. The speed of the wagon isregulated by brakes upon the front wheels, connected with an uprightlever pivoted in the middle part of the frame and provided at its upperend with a crosshead, so that it can be operated either with… … 358. SAIL-RIGGED MERRY-GO-ROUND, St, Malo, France.

Mechanical movements
