Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 161

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 161
alve to a vaporizing retort and bya Bunsen-burner jet is mixed with airand forced into the burner tube, whichis perforated with small holes that feedthe heating flame. 387. KEROSENE OIL BURNER for stoves. The coil of ironpipe in the box is the vaporizer, terminating in the cross pipe and two jet… … GAS AND AIR-GAS DEVICES, ETC. l6l 388. KEROSENE COOK STOVE. National Oil Heating Co.type. Air is compressed in the oil tank above the oil, which drives the oil to a vaporizer in the burner pan,where the oil is vaporized and forcedthrough a combination air jet to thechamber of the burner box, which…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
