Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 163

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 163
in the zones, F, by the airpassing in at the lower part. The waste heatis conducted away in the upper part of the kilnthrough the chimney openings at G. At H aresight holes for judging the heat of the kiln, andJ are holes to admit air when the flues have tobe burned out. The fuel used in the gas… … SECTION X. ELECTRIC POWER ANDDEVICES. 163 Section X. ELECTRIC POWER AND DEVICES. 392. ELECTRIC CABLE-MAKING MACHINE. A revolvingframe carrying the required number of wire bobbins. The strands aregathered by passing through a die and covered in reverse wrappings TO CABLE REEL

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
