Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 196

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 196
blade isprecisely alike, so that if one should bebroken a duplicate could be readilyfitted. A collar is secured upon the shaft,and the inner legs of the blades bearfirmly against it. The sleeve, B, keepsthe legs of the blades at the properdistance apart, and the collar, C, andnut secures all in… … 196 NAVIGATION, VESSELS, MARINE APPLIANCES, ETC. 489. FEATHERINGBLADE PROPELLER.A foot-power propellerwith paddle blades tohang over the sides at thestern, or may be placed inan extension at the stern,as shown in the cuts.The longest movement ofthe paddle is when it isimmersed, and the pad-dle…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
