Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 217

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 217
553. TYPES OF MOTOR BI-CYCLES. F. N. The motor isclamped in a vertical position in thefront frame, with a belt drive to apulley fastened to the spokes. Motorappurtenances inclosed in a case fit-ting the upper part of the frame. MOTOR BICYCLES. The Werner. Themotor in a vertical position is… … 555. TYPES OF MOTOR BICYCLES. Royal Enfield. The motor is secured to the steering head by bracketclamps. The motor drives direct bya long crossed belt to the rear wheelpulley. The front wheel is providedwith a band hub brake, and also oneon the rear wheel hub. 556. TYPES OF MOTOR BICY-CLES. Ladies…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
