Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 26

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 26
13. TWO WAY CON-VEYOR. Method by which arope and disk conveyor can bemade to change its direction.For grain, gravel, sand, clay,and other loose material. … 14. ROPE TRAMWAY CAR-RIAGE. Bleichert System. Theupper rope is the bearing cable andtrolley, the lower one is the haulingrope with the grip device attachedto the car frame. The pull of alanyard starts or stops the car. 15. Shows a side view of theopen car frame and grip cam. 16. FRICTION PULLEY.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
