19. VARIABLE POWER ANDSPEED with friction cone pulleys andtraversing pulley as applied to a drillingmachine. The transmitting roller ispivoted in a frame that slides on a sidebar and is clamped by a screw at theposition required for the desired speed.See No. 106, ist vol., for a frictionlessform of… … 3 PITCH2 THREADS 20. WORM GEARELEVATOR. Spraguetype. The double wormand gear serves the pur-pose of balancing thethrust of the driving shaftand is also a means ofsafety from breakage ofteeth. The wear on theworms and gear is alsomuch lessened by theirduplication. TRANSMISSION OF POWER. 27 21. CASH…
