Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 282

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 282
729. DRY GOLD MINING MACHINE. The hand crank wheel, the vibrator, and theblower for blowing off the dust and sand fromthe riffle table are the leading features of thisnovel dry placer machine. Gold sand is fed tothe hopper above and shaken in a thin sheet tothe rifBe through a blast of air. Air is… … 730. GOLD AMALGAMATOR.a, the circular tank with sluicewaysfor overflow of the waste slimes. c, c, revolving stirring arms drivenby the gear and center shaft throughthe conical center standard of thetank. The amalgamated plates ormercury rests on the bottom of thetank. m, f, perforations in the disk…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
