Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 304

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 304
ring, so as to produce any desired graduation in the strength ofblow of the chisel, d, is brought about by increasing or diminishing theeffective radius of the cam to increase or diminution in the height of liftof the ram h. The cam is made tapering in the direction of its axis andis mounted upon… … 304 MILI, AND FACTORY APPLIANCES AND TOOLS, ETC. 802. DOVETAILS.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
