Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 322

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 322
the pestle drivendown by a hammer. The pieces of brokendiamond are examined for the detection offragments suitable for gravers, drills, and etch-ing points. The remainder is crushed to animpalpable powder by several hours continuedwork, rotating the pestle between blows. When sufficient fineness is… … Section of the grinding mill. 833. DIAMOND HAND TOOLS AND DRILLS. In Fig. a, aare front and side views of diamond chisels used in turning rubies for watch-jeweling ; ^ is a diamond drill for mak-ing the hole in the ruby plate ; (/ is a tool ofsteel wire to be used with diamond dust indrilling…

Mechanical movements
