Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 342

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 342
873. REVERSIBLE PLOW. The wheel runs in the last furrow.;), yoke handle, which turns over tothe other side at the end of a fur-row ; V, latch to fasten the handleto the beam ; /, k, clevis and chain. TETHERING … HOOK. The hook or fastening for tetheringor coupling animals by their bridles, etc., andfor other uses, comprises a link, c, and a hook, a,the point of which can not pass through the link.The hook has holes for the link and the fixing-staple h. The strap, 5, is attached to the fasten-ing as shown.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
