Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 380

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 380
The stationary sector gear. A, rolls the small pinions which, by a rod connection with thefollowing edge of the hingedweights on the periphery of thewheel, tilt the weights upwardand outward, making a prepon-_ derance on that side of the wheel. 7 /!„/ \r?^^.^i^g;ir-::^==H=T^/^-^ Pl^g same operation…
