Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 391

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 391
heel. The star wheel isarranged to tilt a lever, whichcarries at its extremity a plate,B, of brass coated with thechemical and mineral sub-stances which make it an in-sulator of magnetism. The per-manent magnet is a U-shapedbar, with its poles near the wheel,A, and opposite the path of… … PERPETUAL MOTION. 389 968. PERPETUAL MOTION. Alternate magnet type. The swing-ing of the outside magnets of oppositepolarity. Alternate the attraction andrepulsion of the magnets on the wheelto generate power to swing the outsidemagnets in and out of their sphere ofaction. Patented 1799.
