81. FLASH COIL BOILER. Made withtwo open coils of iron pipe interlocked so thatthe central space is occupied by a useful steam-generating surface. This form gives a large generating surface in asmall space. … 82. FINGER TUBE BOILER. The shell is made of thick tubing for small boilersor y^ inch plate for larger size. The fingersare of short pieces of pipe welded at one endwith a square head for a wrench and screwedinto the shell, using ordinary pipe threads.The connecting tubes are not essential andmay…
