Plan and section of the crude oilburner used on theSouthern Cali-fornia Railroad.This burner hasbut two chambers, oil andsteam; the air enters the fur-nace through graduated open-ings around the burner. 103. Mouth of burner. 104. Plan of burner. 62 GENERATION OF POWER, STEAM. … 105. BURNER FOR AUTO-BOIL-ER. The disk chamber is stamped out ofplate iron. The interior air tubes arescrewed into the back head and furnish airto complete combustion. The outer tubesare screwed into the top plate and furnishan annular stream of vapor gas from thechamber below. 106.burner…
