Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 64

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 64
ly combines them and spreadsthem outward at the same time.The air pipe connects with achamber D, which has a cockfor draining off water. A valveis provided between D and C forcontrolling the pressure. Theoil pipe connects to the back ofC, and is carried through C by apipe G which terminates with… … 114. OIL FUEL BURNER.

Mechanical movements
