Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 70

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 70
g into theexhaust pipe. The feed pump takes the hot water from the reservoirat a point near the bottom, thus avoiding any oil that might be presentat the surface. 135. SURFACE CONDENSER. Double tube type in whichthe shell has both tube heads at one end ; the cooling water flowing through the… … 70 GENERATION OF POWER, STEAM. 136. NOVEL SURFACE CONDENSER. A cylinder filledwith small tubes as shown in the section, 137. A spray jet of water

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
