Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 122

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 122
TOR STARTER. A starting wheel B,with oblique saw teeth, is fixed on the motor shaft A. A sprocket chain C, C is wound on adrum containing a coiledspring D, so arranged as torewind the chain with a stopJ, so as to allow it to hangfree from the ratchet wheelwhen the finger loop at E isdropped to the… … I20 EXPLOSIVE MOTOR POWER AND APPLIANCES.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
