Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 129

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 129
.,„,---,;«. ■••i_--,-^:^^^ frame on piles, or on floats in a stream, shows increased power by thelarge number of submerged buckets. 295. FLOATING MOTOR FOR RIVERS. A wheel of thewindmill type is hung within a bell-mouthed case, which may be … lowered or drawn up to clear the varying depth of a stream and toutilize the full value of the increased velocity at mid depth. Poweris transmitted to the shore, or may be used on the floats for pumpingwater for irrigation. 296. Cross section, showing wheel and frame. 297. WATER MOTOR. A curved…

Mechanical movements
