Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 138

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 138
324. COUNTERBALANC-ING HYDRAULIC ELEVA-TORS. Showing the arrange-ment of valves, cylinder, circulat-ing pipe for up and down motionof the hydraulic piston and thedistribution of the counterweightsto equalize the power. The de-tails of operation are shown by thelettering on the cut. HYDRAULIC POWER… … 329- 326.direct connection with a pump, as shown in No. 328 325. RE-ENFORCIN GWELLS. The re-enforcement ofwells in times of drought may bereadily made by making a cylin-der of galvanized iron, punchingit with a thin chisel, as shown inthe cut, 326, inserting it and push-ing it down in the bottom of…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
