Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 158

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 158
amylic alco-hol, after care has been taken to fill thereservoir, P, with oil after unscrewing theplug A. The alcohol is lighted, and assoon as the worm is hot the cock isopened, the jet takes fire, and the ap-paratus is ready for use. Upon the stovethere may be placed either a cast-iron potin which… … 156 GAS AND AIR-GAS DEVICES, ETC. WORKING STAGE 377, PRODUCER GAS GENERATOR. German type. A,door for feeding coke to the furnace B and for blowing up. C, fire- s brick walls of the furnace. E, air inlet for heating thefurnace of the generator.F and G, gas blow-off pipe,interchangeable to reversethe…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
