on at the stern,as shown in the cuts.The longest movement ofthe paddle is when it isimmersed, and the pad-dle being vertical, there isno splash, sHp, or loss ofpropulsive effect arisingfrom the obhque action. 490. The curve traversed by the edge of the paddle. 491. The extension of the paddle box.… … 26 inches. Wheel 20 inches diameter, 30 inch pitch, with or withoutsteel wheel guard. Motor, 12 horse power. Displacement with pas-sengers, 2,000 lbs. Elevation and midship sections. 495. Sectional elevation of frame, motor and propeller. 496. Plan with lines of upper works. NAVIGATION, VESSELS,…
