Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 218

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 218
549. TYPES OF MOTOR BICY-CLES. The Brown. Much after the styleof the Derby, but driven by a belt from themotor pulley to a pulley attached to the rearwheel. 550. TYPES OF MOTOR BI-CYCLES. The Minerva. The motorhangs beneath the lower reach anddrives by belt over a pulley on rearwheel. Has a surface… … 551. TYPES OF MOTOR BICYCLES. The Singer. Themotor and all its appurtenances, including fuel tank, are within the rear wheel, which, with the exceptionof the controlHng rods and levers, is inde-pendent of the rest of the bicycle. Themotor is hung on a fixed shaft with itscrank shaft below the axial…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
