Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 226

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 226
68. MULTIPLE PLATE FRICTIONCLUTCH. Pattern of the main drivingshaft clutch, Brooklyn Bridge. Every otherring plate is keyed to the inner sleeve andflange; the alternate rings are keyed todriven shaft-flanged hub. A toggle, oper-^^ ated by the collar and a yoke lever, pressesthe ring plates together… … 571. Cast - steelbox case riveted towrought iron frame.

Mechanical movements
