Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 230

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 230
M-PRESSINGSTEEL CARWHEELS. Fow-ler type. Fivesmall wheel treadrolls spaced aroundthe hot car wheelare revolved andpressed to thewheel rim, re-ducing its diam-eter a half inch. Theinner form of the wheelkept true duringthe rolHng by moldsclamped to each side.The small sectionshows the clampedwheel.… … 590. REVERSING CAR SEAT. A shiftingback seat actuating a foot rest when shifted, tomove into proper position to carry it out of the wayof the occupant of the seat and leave a baggagespace under the seat, while at the same time, bythe same movement, the foot rest is properly placedfor the occupant…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
