Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 252

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 252
SacJsiiS^^ 648. RECIPROCATING MOTIONwith a stop at each stroke from uniformcrank motion. The crank pin follows theopposite curves in slot at each half revo-« lution. Rebounding at the wide part ofthe slots is opposed by buffer springs. 649. RECIPROCATING INTO ROTARYMOTION WITHOUT DEAD CENTERS.The… … 650. RIGHT-ANGLECOUPLING for revolvingshafting. A, driving shaft and crank.B, driven shaft crank. C,point of intersection of shaftcenters. D, driving crankpin, pointing to the center C.E, connecting arm. F, oscil-lating piece with pins point-ing to the center C. G, con-necting arm to crank pin…

Mechanical movements
