Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 26

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 26
8. QUICK COUPLING for sewer rods. Makes a smooth contin-uous rod that can not uncouple whilein use. … 9. TRANSMISSION of powerby wire rope and anchored levers.The braced tee pieces A B, withtheir arms connected with a distantrocker by the wire W W, pivotedto the windmill frame and to thecrank rod at A, make a very effec-tive method of operating a pumpat a distance. A strong fencewire is sufficient…

Mechanical movements
