Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 277

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 277
710. WELL-BORING TOOLS. d, broad edge reamer ; e, composite flaring reamer ;/, shoulder reamer ; g, double-cutting cross reamer ;h, spring circular blade reamer, allfor truing and enlarging holes. … td 711. WELL-BORING TOOLS.i, the drill stem or sinker bar ;j, drill jars to give a hammer action to the drill;k, short sinker bar above the jars;/, temper screw to adjust the length of rope for properly operating the jars and drill;m, clevis or walking-beam strap. 712. WELL-BORING TOOLS. Sand…
