Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 297

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 297
-CHINE. For the shape shown the top rolleris flat ; the rear under roller is grooved to fitthe flange of the angle iron. The front rolleris also grooved and is set up for the desiredcurve by a sliding frame and capstan screw. 769. ROLLED-THREAD-SCREW MACHINE. The cut shows the principle of the… … 771. POWER HACK-SAW. One of the handy specialties of a shop. Automatic-ally cuts off steel bars up to 4-inch diameter.Self-feeding and requires no attention whilecutting. MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 295 772. SEAMLESS TUBE MACHINE. Mannesmanns process.The principles in this process…
