Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 300

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 300
783. OIL OR GAS FIREDAil* FORGE. Oil or gas enters the ato-mizer by the small pipe and is mixed atthe nozzle by a strong blast of air. Ad-ditional air jets to complete the com-bustion enter beneath the bed of thefurnace. … 784. MELTING FURNACE for brass,copper, or bronze. Operated by gas orcrude oil, and compressed air. Oil or gas is fed through the small pipe,atomized and mixed with air in the inletnozzles at the top of the cupola and the flameprojected down upon the metal. The cupolais tipped by the wheel and gear…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
